Multi voltage Digital Thermometer Red

Multi voltage Digital Thermometer Red

BREAKERMATIC TED300-MVREST

voltage: 80V to 240V AC

for refrigerated cabinet or display cases, for soft drink or beer displays, meal, etc.

SKU: TED300-MVREST
Category:
Nominal Voltage Min. 75 Vac / Max. 270 Vac
NTC sensor measurement range -40º C a 40º C
Nominal Power 3.5 VA
Resolution 0.1º C (entre -9.9º a +9.9º) / 1º (en el resto del rango)
Download Catalog(s)
Digital Thermometers catalog (eng.)
Digital thermometers technical datasheet (eng.)
Labels: , , , , , , , , ,
SKU: TED300-MVREST
Category:
Nominal Voltage Min. 75 Vac / Max. 270 Vac
NTC sensor measurement range -40º C a 40º C
Nominal Power 3.5 VA
Resolution 0.1º C (entre -9.9º a +9.9º) / 1º (en el resto del rango)
Download Catalog(s)
Digital Thermometers catalog (eng.)
Digital thermometers technical datasheet (eng.)
Labels: , , , , , , , , ,

The BREAKERMATIC © TED300 is a digital electronic thermometer designed to display the temperature of a specific environment using its 8-segment LED display with 30 mm digits. It offers a temperature range from -40°C (-40°F) to 40°C (99°F) and can be configured to display the temperature in degrees Celsius or Fahrenheit.

The temperature sensor is a solid-state semiconductor device of the NTC type. It comes with a 1.5 m connection cable.

The TED300 connects directly to the electrical supply of the refrigeration equipment or cabinet and can operate on either 120VAC or 220VAC.



Uses

The TED300 is used to display the temperature of refrigerated cabinets or display cases, such as refrigerated display cases for beverages, wines, meats, or dairy products, etc. It can also be used to display ambient temperatures.

Ideal for use as a marketing aid by displaying the temperature of the beverage cabinet at the point of sale.



Features

  • Large 30 mm high digits for easy viewing.
  • NTC sensor with 1.5 meter cable.
  • Can display °C or °F
  • Multi-voltage, can be used equally well on equipment operating on 120 VAC or 220 VAC
  • Does not require external transformers or complicated connections.
  • Low power consumption.
  • Housing can be recessed into chassis or panels.
  • Display color: Red.
